Controller:
|
|
|
Keyboard: |
|
|
49-full size keys with 8 velocity curves
|
|
|
Rotary Encoder x 8, main encoder
|
|
|
Slider x 8
|
|
|
Pad x 16 (velocity sensitive)
|
|
|
Vector Joystick (independent X and Y assignments)
|
|
|
PITCH Wheel (independent Up and Down assignments)
|
|
|
MOD Wheel
|
|
|
Switch x 2
|
|
Display:
|
|
|
Main Display: |
|
|
8 characters (8x5 dot) three-color backlit LCD module
|
|
|
Sub Display: |
|
|
8 characters (8x5 dot) three-color backlit LCD module
|
|
|
MIDI Clock/Tempo LED
|
|
Memory:
|
|
|
Preset (user) Memory x 12
|
|
|
Global Memory
|
|
Connections:
|
|
|
Pedal
|
|
|
Switch
|
|
|
MIDI: |
|
|
IN, OUT, OUT
|
|
|
USB
|
|
|
DC IN
|
|
Power:
|
|
|
USB bus power (in USB connection)
|
|
|
DC9V (AC adapter)
|
|
Power consumption:
|
|
|
USB bus power: |
|
|
approx. 350mA (max. 450mA)
|
|
|
AC adapter: |
|
|
approx. 450mA (max. 500mA)
|
|
Others:
|
|
|
Dimensions: |
|
|
28.74� (W) x 12.56� (D) x 3.39� (H)
730 (W) x 319 (D) x 86 (H)mm
|
|
|
Weight: |
|
|
10.8 lbs. / 4.9kg
|
|
|
Accessories: |
|
|
AC adapter, USB cable, CD-ROM (KONTROL49 Editor/Librarian
software for Mac OS X/Windows XP, templates scene data, KORG
USB-MIDI driver for Windows XP, demo software), name sheet &
sticker for trigger pads
|
|
System requirements Macintosh:
|
|
|
Supported OS: |
|
|
Mac OS X v10.2 or later (v10.3 supported)
|
|
|
Supported Computer: |
|
|
Apple Macintosh supported Mac OS X with USB port
Note: USB MIDI has been tested and works under Rosetta and
Universal Binary on Intel-based Macs, using the standard Class
Compliant driver. In this case, however, Port Names will be
shown as generic names like Port 1, Port A etc. instead of the
product name. The Editor has been tested on Intel-based Macs,
and while not Universal Binary compliant, runs fine under
Rosetta.
The Editor / Librarian is available for Windows XP or Mac
OS-X.
Click here for
additional information and to download the correct one for
your computer.
Mac Users: USB MIDI has been tested and works under Rosetta
and Universal Binary on Intel-based Macs, using the standard
Class Compliant driver. In this case, however, Port Names will
be shown as generic names like Port 1, Port A etc. instead of
the product name. The Editor has been tested on Intel-based
Macs, and while not Universal Binary compliant, runs fine
under Rosetta.
|
|
System Requirements Windows:
|
|
|
Supported OS: |
|
|
Microsoft Windows XP Home Edition / Professional
|
|
|
Supported Computer: |
|
|
PC supported Windows XP with USB port (Intel USB chip set
recommended)
|
|
Options:
|
|
|
PS-1 Pedal Switch
|
|
|
DS-1H Damper Pedal
|
|
|
EXP-2 Foot Controller
|
|
|
XVP-10 Expression / Volume Pedal
|
|
Specifications subject to change without notice |
